Aruba 8 Port Poe Switch
Original price
80.000 KD
-
Original price
80.000 KD
Original price
80.000 KD
80.000 KD
-
80.000 KD
Current price
80.000 KD
| Model No | Aruba 8 Port Poe Switch |
| Part No | JL681A |
| Interfaces | 8 x 10/100/1000 Mb/s Gigabit Ethernet (RJ45) PoE+ (Type 2) 2 x 10/100/1000 Mb/s Gigabit SFP |
| Layer Services Supported | Layer 2 Support |
| Supported Protocols | Auto-MDIX/MDI Auto-VoIP IGMP Snooping IPv4 IPv6 Link Aggregation Port Mirroring SNMPv1 SNMPv2c SNMPv3 |
| Queuing | Strict Priority, Weighted Round Robin (WRR) |
| Jumbo Frames Support | 9216 Bytes |
| MAC Address Table Size | 8K |
| Security Features | DHCP Snooping DoS Attack Prevention RADIUS Authentication Storm Control |
| Access Control List | 50 |
| Standards | 802.1ab, 802.1d, 802.1s, 802.1w, 802.1x, 802.2az, 802.3, 802.3ab, 802.3ad, 802.3af, 802.3at, 802.3p, 802.3q, 802.3u, 802.3x, 802.3z |
| Latency | 5.2 µs |
| Forwarding Rate | 14.88 Mpps |
| Switching Bandwidth | 20 Gb/s |
| Priority Queues | 4 |
| Packet Buffer | 64 B |
| Flash Memory | 256 MB |
| RAM Buffer | 1.5 MB per Device |
| Power | Power Draw: 150.2 W (Max) 11.7 W (Idle) AC Input Power: 100 to 240 VAC, 50 / 60 Hz at 0.8 to 1.6 A PoE Power Budget: 124 W PoE per Port: 30 W Power Supply Type: Internal |
| Cooling System | Passive |
| Special Features | 8 x Gigabit Ethernet Ports 8 x PoE+ Compliant Ports 2 x SFP Ports 20 Gb/s Switching Capacity 14.88 Mpps Forwarding Capacity 800 MHz ARM Cortex-A9 Processor 512MB RAM Rack-Mountable Design 124W Power Budget Built-In Security Features |
| Dimensions | 10 x 10 x 1.73" / 25.4 x 25.4 x 4.39 cm |
| Weight | 2.56 lb / 1.16 kg |
| Warranty | 1 Year ( As per Manufacturer Policy ) |
Key Features
-
Item ID : NS009772
-
Brand : ARUBA
-
Color : White
